Turn Key Solusion / CS
APIS with people, technology and customers
Pretreatment
(honing machine,
ultrasonic cleaner)
After treatment
(Honing machine, film removal device, sand blasting)
analyzer
(Callo tester, Rockwell hardness tester, etc.)


Turn Key Solution
Surface post-processor to improve surface finish
Characteristic
▸ Equipment for surface polishing
▸ Basic jig: 4 axes x 6 pieces (quick change type)
▸ Size : 0.9m(L) x 1.2m(W) x 2.2m(H)
▸ Applications: Drills, hobs and general parts
▸ Weight: 380Kg
▸ Electrical Specifications: 220/380V x 50/60Hz
Turn Key Solution
It is a peeler using a chemical peeler, and the size may change depending
on the size of the product.
Characteristic
▸ Type: Manual
▸ Tank capacity: 100liter
▸ Operating temperature: 60~100°C
▸ Separate space and ventilation facilities required
▸ Separation into peeling tank and drying tank
▸ Size: 3.1m(L) x 0.8m(W) x 0.9m(H)
▸ Electrical Specifications: 220/380V x 50/60Hz
▸ Chiller 3RT
Turn Key Solution
Characteristic
▸ High pressure sandblasting machine
▸ Nozzle injection method
▸ Size: 1.4m(L) x 1.4m(W) x 2.4m(H)
▸ Door size: 700mm(W) x 670mm(H)
▸ Electrical Specification: 220/380V x 3Kw
▸ Air consumption: 8m/3min (15HP, excluding air compressor)
▸ Size: 1.4m(L) x 1.4m(W) x 2.4m(H)
